DLF Anti-Glare LED Downlight

Deeply LED Inside with Anti-glare rings  UGR<16
COB or SMD Model Optional with different beam angle
4 colors of reflectors  optional for different application
IP Rating : IP44 / IP54
Voltage :AC 220-240V  AC100-277V
Lumen efficiency : 100LM/W
Color Temp. 2700K 3000K 3500K 4000K 5000K or Customized
CRI :  >90Ra  >95Ra
Housing material :  Die-cast Aluminum
Dimmable : ON/OFF / Triac Dim/ 0-10V Dim/ DALI Dim
Housing color: Matt White, Matt Black,
Lamp Certificates: CE ROSH SAA
Warranty : 5 Years
Delivery time : 3-4 days for sampes ,7-15 days for bulky orders

    DLF downlights range with shielded light source and precise cut off reflectors reduces glare and improves visual comfort. Combined with variety of color plating reflectors meet the requirement of different application ,it provides different solution for project and distribution with different product type: COB/SMD version,  different sizes, different watts.



    Model No.

    Input voltage(V)

    Power (w)

    LED Chip

    Luminous flux (lm)  (±5%)

    Beam angle(o)

    CCT (K)

    CRI

    Size (mm)

    Cutout(mm)

    OP-DLF9W F1

    AC220-240V

    AC100-277V

    9W

    OSRAM

    100LM/W

    15/24/36

    /60(SMD)

    2700K 3000K

    4000K 5000K

    80+/90+

    D90*H80 mm

    Ø75mm

    OP-DLF15W F1

    AC220-240V

    AC100-277V

    15W

    OSRAM

    100LM/W

    15/24/36

    /60(SMD)

    2700K 3000K

    4000K 5000K

    80+/90+

    D114*68mm

    Ø95mm

    OP-DLF20W F1

    AC220-240V

    AC100-277V

    20W

    OSRAM

    100LM/W

    15/24/36

    /60(SMD)

    2700K 3000K

    4000K 5000K

    80+/90+

    D140*74mm

    Ø120mm

    OP-DLT30W F1

    AC220-240V

    AC100-277V

    30W

    OSRAM

    100LM/W

    15/24/36

    /60(SMD)

    2700K 3000K

    4000K 5000K

    80+/90+

    D184*80mm

    Ø150mm
